Brand Name : | YUE MI |
Model Number : | 59U/58U |
Certification : | ISO SGS |
Price : | consult |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability : | 100/Set/Month |
Delivery Time : | 5-8 word days |
Mechanical Seal Sulzer Pump Hydraulic Pump Oil Seal PTFE Water Pump Shaft Seal
Performance Capabilities | |||
Temperature | -50°C to 500°C, dependent on the elastomer | ||
Pressure | Up to 10 bar | ||
Speed | Up to 20 m/s | ||
End play/axial float allowance | ±0.1mm | ||
Sizes | 14mm to 100mm |
Combined material
Face:Carbon, SiC, TC
Seat: Ceramic, SiC, TC
O-ring: PTFE
Spring: SS304, SS316
Metal parts: SS304, SS316
Features
1,A versatile design with multiple material options for the widest range of liquids and temperatures.
2,An unbalanced seal with the advantage of being a very short unit fitted to a straight through shaft.
3,Multiple Springs ensure even face loading while compensating for acceptable shaft misalignment.
Recommended Application
1,Process Pumps
2,Other Rotating Equipment
O-Ring Mechanical Series Operational Conditions: Temperature: -40ºC+250ºC Pressure:≤1.2MPa Speed:≤15m/s | Materials: Stationary Ring:V1,Q1,U2 Rotary Ring:B,A,U2,Q2 Secondary Seal:T Spring and Metal Parts:F,G,M Seat Type:. Standard :HMBP, Alternative: HMBO |
1.Applicatons:Clean water,sewage water,oil and other moderately
corrosive fluids. 2. Our seals can replace the original seals. 3.Standard:the products are in according with Din24960,ISO3069,en12576,API682 standards 4.OEM and Customized products is welcomed. 5. Factory Price,High Quality ,Fast Delivery and Best Sevice. |
![]() |
