    560A Single-Spring Water Pump Mechanical Seal Replace Aesseal replace MTU FP/T3S

    Ask Lasest Price
    Brand Name : YUE MI
    Model Number : 560A
    Certification : ISO SGS
    Price : consult
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000/Set/Month
    Delivery Time : 5-8 word days
    • Product Details
    • Company Profile

    560A Single-Spring Water Pump Mechanical Seal Replace Aesseal replace MTU FP/T3S

    Product Description


    560A series mechanical seals can be used in pipeline circulating pumps for water supply, district heating system, industrial wastewater treatment, boiler feed water, etc. They are suitable for sealing of oil, water, salt, non-crystallizing solvents and other weakly corrosive fluids, and are characterized by the structure of internal mounting, single-end face, large spring, and rubber bellows structure.

    Working Conditions
    Pressure≤0.8 MPa
    Temperature-20~150 ºC
    Speeds≤10 m/sec
    Combination Materials
    Rotary ringcarbon, resin-impregnated B
    tungsten carbide, cobalt-bound U1
    tungsten carbide, nickel-bound U2
    silicon carbide without free silicon Q1

    silicon carbide with free silicon Q2
    Stationary ringtungsten carbide, cobalt-bound U1
    tungsten carbide, nickel-bound U2
    silicon carbide without free silicon Q1

    silicon carbide with free silicon Q2
    Alumina V
    Auxiliary Sealnitrile synthetic rubber P
    EP synthetic rubber E
    fluorocarbon synthetic rubber V
    Spring or other metal partsCrNi steel F
    CrNiMo steel G
    Materials according to operating condition

    560A Dimensions(mm)
    dD3D1L2L1
    818.221712.2
    918.224716.2
    1020.624716.2
    1120.624716.2
    1221.826717.2
    1321.826717.2
    1426.428718.2
    1526.428718.2
    1626.432819.2
    1729.532819.2
    1829.535819.2
    1929.535819.2
    2031.638820.2
    2233.640820.2
    2539.644920.2
    284546921.2
    3046.650922.2
    3246.654924.2
    3550.8581026.2
    3854.3601027.2
    4057.3641028.2
    4561.3661030.2
    5067.8721032.2


    FAQ

    Question 1: Are you a factory or a trading company?
    Answer: We are a factory manufacturing mechanical seals. We have regular models in stock and customized products are also available. Please feel free to contact us if you need any.

    Question 2: What is the minimum order quantity for each order?
    Answer: For products of regular models, the minimum order quantity is at least ten. We welcome you to test the quality of our products and our services through small orders and look forward to long-term cooperation with you next.

    Question 3: How can I pay my order?
    Answer: We accept T/T, Paypal, D/P, Western Union, Money Gram to pay.

    Question 4: Can I try to get a Sample before the order?
    Answer: Sure. But our company can not provides you with samples for free, and you also have to pay for the international delivery (freight collect payment).
